Coolant Distribution Unit (CDU)

TCDU

Coolant Distribution Unit (CDU) Single Closed Left

Overview

The most capacity of any coolant distribution unit of its size.

Introducing Trane's next-gen Coolant Distribution Unit (CDU) up to 10MW cooling capacity, delivering efficient direct-to-chip liquid cooling for hyperscale and colocation data centers. This compact Cooling Distribution Unit reduces energy use and costs while ensuring top performance and scalability.

  • Integrated ATS with supercapacitor
  • 25-micron filtration
  • Up to 10MW cooling capacity in compact footprint
  • Front service access

  1. Powerful direct-to-chip cooling capacity

    Engineered for high-density data centers, supporting IT equipment with a power consumption of up to 10MW.

  2. Space-saving, rack-based design

    Rack-based form factor with no side access required so units can be installed tightly side-by-side. Ideal for retrofit data centers that need to maximize white space while providing high-capacity direct-to-chip cooling.

  3. World-class service and support

    Choosing Trane CDU liquid cooling gives you access to expert resources and support from Trane no matter where your operations are located. You’ll be supported by a team of data-center-qualified technicians who understand the unique challenges of your industry.

Product Information

  • Modular Scalability: Supports cooling capacities up to 10MW, adaptable to various data center sizes and needs.
  • Direct-to-Chip Liquid Cooling:  Optimized for high-density data centers, ensuring efficient heat transfer directly from IT equipment.
  • Compact Footprint:  Provides up to 10MW cooling capacity in a space-saving design, with front only panel access for easy maintenance.
  • High Head Pressure:  >50 psi head pressure allows for longer runs between the Coolant Distribution Unit (CDU) and server racks.
  • Dual VSD Pumps:  Dynamic response to cooling demand enhances energy efficiency and reduces operational costs.
  • 316 stainless steel plate heat exchanger:  Compatible with various coolant fluids, offering corrosion resistance and high performance.
  • High Flow Rate:  Capable of a maximum flow rate of 3,600 liters per minute for rapid heat absorption and transfer.
  • World-Class Service and Support: Access to expert resources and data-center-qualified technicians from Trane for reliable service and support.
Trane CDU Performance
Delta-T (TCS)
10°C
12°C
13°C
Max flow rate (TCS)
1,500 lpm
1,500 lpm
1,500 lpm
Glycol rating
PG 25
PG 25
PG 25
Cooling capacity (4°C ATD)
1,004 kW
1,202 kW
1,350 kW
Heat dissipation ratio
1.50 lpm/kW
1.25 lpm/kW
1.15 lpm/kW

Product Literature

Brochures

Product Data Sheets

Installation Operation Maintenance (IOMs)

Related Products

  • Trane® Ascend™ Air-Cooled Chiller model ACR

    Ascend™ ACR Air-Cooled Chiller

    Model ACR

    Trane® Ascend™ ACR with integrated free cooling, engineered for high-density environments. Exceptional efficiency and Rapid Restart™.

  • Trane® Air-Cooled Magnetic Bearing Chiller model TCAB

    Air-Cooled Magnetic Bearing Chiller

    Model TCA

    Maximize cooling efficiency and reduce costs with Trane’s Air-Cooled Magnetic Bearing Chiller. Ideal for data centers, it offers advanced control and sustainability. Request a quote today!

  • Fan Coil Wall Painted Full Front with Background - Data Centers - TCDC

    Fan Coil Wall for Data Centers

    Model TCDC

    Trane's data center fan wall unit maintains precise temperature and humidity in server rooms, helping mission-critical data center uptime and reducing energy consumption.

FAQs

Your CDU questions answered.

A coolant distribution unit (CDU) is an HVAC cooling solution for data centers. The CDU moves liquid coolant through the system so the equipment doesn’t overheat and can run safely and efficiently.

A CDU works by pumping coolant through the racks of IT equipment, where the liquid picks up heat. Then it brings the warm coolant back, removes the heat, and sends cooled liquid out again.

CDUs also monitor temperature, pressure, and flow so everything stays in the right range. Some systems use direct‑to‑chip cooling, where the coolant flows through plates that sit right on top of the chips to pull heat away more quickly.

Liquid cooling with CDUs is more efficient than air cooling, especially in hyperscale data centers. It helps save energy and keeps temperatures more stable. CDUs are also reliable, have sensors that catch issues early, can scale as cooling needs grow, and work with different types of coolants and setups.
